| Mimosa B5c (100-00014), 802.11ac 5GHz PTP Backhaul | ||||
| 30 dB - 5 GHz | ||||
| Group | Wireless AP | |||
| Manufacturer | Mimosa | |||
| Manufacturer item no. | 100-00014 | |||
| EAN/UPC | 5902560368987 | |||
| Description | ||||
| Mimosa B5c, 802.11ac 5GHz point to point radio link unit without antenna, Mimosa B5c, 802.11ac 5GHz point to point radio link Unit without antenna Max Throughput Up to 1.5 Gbps IP aggregate UL/DL (1.7 Gbps PHY) Low Latency Configurable 5ms+Wireless Protocols TDMA, TDMA FDMIMO & Modulation 4x4:4 MIMO OFDM up to 256QAM bandwidth* Single or dual 20/40/80MHz channels frequency range 4900-6000MHz restricted by country of operation (*new* US/FCC 5600-5650 support) Max Output Power 30 dBm (2-stream), 27 dBm (4-stream) Sensitivity ( MCS 0 ) -87dBm@80MHz-90dBm@40MHz-93dBm@20MHzMax PowerConsumption 20W System Power Method 48 V DC 802.3 at compliant power injectors system Lightning & ESD Protection 6kVPoE power supply Passive POE compliant, 48-56V Power over Ethernet supply with IEC61000-4-5 surge protection Outdoor Ingress Protection Rating IP67 Gigabit Ethernet 10/100/1000-BASE-T2x Female Type N for external antenna--> external antenna is still needed! | ||||
| Extended details | ||||
| General | ||||
| Type | Wireless AP | |||
| Transmissionrate | 1700 Mbps | |||
| Network protocols | TCP/IP | |||
| Network standards | Ethernet; Power over Ethernet | |||
|
|
||||
Mimosa B5c (100-00014), 802.11ac 5GHz PTP Backhaul
https://www.mimosa.co/b5c
Ultra Rugged
Carrier-grade IP67 design allows the B5 and the B5c to withstand the harshest of environmental conditions.
Easily Add New Links
Typical backhaul solutions waste spectrum with every link installed and impacting network capacity. Unique high-precision GPS Sync technology allows Mimosa B5 and B5c products to reuse the same channel network wide, and up to 4 links can auto-coordinate.
Double Reliability
Unlicensed spectrum can be unpredictable. So Mimosa custom engineered unique multi-channel and auto-everything technology to protect your links when you encounter interference. The B5 and B5c automatically keep your links up with two independent operating channels, and adapting using our auto-everything technology to resolve problems proactively to deliver optimal link speed and reliability. It's like two smart links in a single radio!
Monitor with Ease, and so much more
Immediately after install, your links are ready to be monitored via the free Mimosa Cloud service. With vast data collection and analysis, assessing link health and identifying potential problems has never been easier. For rich analytics and historical data collection, and problem notifications, the Mimosa Cloud+ service is available to monitor your entire network for only $99 USD per year.
